Agricultural Machinery Bearing Carbon Steel Bearing 206KRR6 HPC100GP 1AH06-1 Special Bearing Plastic Drum Packaging
206KRR6 Agricultural Machinery Bearing
25.400*62.000*24.000mm Bearing Features:
Inner Ring Diameter (bore):1 Inch
Outer Ring Diameter:2.4409 Inch
Width:0.9450 Inch
Dynamic load:4370
The static load:2320
Weight:0.75KG
206KRR6 Agricultural Machinery Bearing Description:
| Model Number | 206KRR6 |
| Inside Diameter: | 1 |
| Outside Diameter: | 2 7/16 |
| Thickness: | 15/16 |
| Seal Type: | Double Shielded, 2RS |
| Material: | Chrome steel, Gcr15 |
| Precision Rating: | P0-P5 |
| Brand: | TOPE or other brands |
| Payment term: | T/T,L/C,Western Union, PayPal |
| Delivery time: | 1-5 days for small amout, 15-40 days for big amount |
206KRR6 Agricultural Machinery Bearing
more models:
| Bearing type | Style | Trunnion | A | D | Be | Bi | Dynamic load | The static load | Weight Lbs. |
| 202KRR3 | 1 | 9/16” | 0.5630 | 1.3780 | 0.4330 | 0.5120 | 2160 | 1000 | 0.12 |
| | | | 14.300 | 35.000 | 11.000 | 13.000 | | | |
| 204KPP2 | 3 | 11/16” | 0.6950 | 1.8504 | 0.5510 | 0.8250 | 2900 | 1000 | 0.34 |
| | | | 17.653 | 47.000 | 14.000 | 20.955 | | | |
| 204KRR2 | 1 | 11/16” | 0.6950 | 1.8504 | 0.5510 | 0.8250 | 2900 | 1410 | 0.32 |
| | | | 17.653 | 47.000 | 14.000 | 20.955 | | | |
| 204KRRB2 | 2 | 11/16” | 0.6950 | 1.8504 | 0.5510 | 0.8250 | 2900 | 1410 | 0.32 |
| | | | 17.653 | 47.000 | 14.000 | 20.955 | | | |
| 205KPP2 | 3 | 7/8” | 0.8760 | 2.0472 | 0.5910 | 1.0000 | 3150 | 1610 | 0.47 |
| | | | 22.250 | 52.000 | 15.000 | 25.400 | | | |
| 205KRR2 | 1 | 7/8” | 0.8760 | 2.0472 | 0.5910 | 1.0000 | 3150 | 1610 | 0.44 |
| | | | 22.250 | 52.000 | 15.000 | 25.400 | | | |
| 205KPPB2 | 4 | 7/8” | 0.8760 | 2.0472 | 0.5910 | 1.0000 | 3150 | 1610 | 0.47 |
| | | | 22.250 | 52.000 | 15.000 | 25.400 | | | |
| 205KRRB2 | 2 | 7/8” | 0.8760 | 2.0472 | 0.5910 | 1.0000 | 3150 | 1610 | 0.44 |
| | | | 22.250 | 52.000 | 15.000 | 25.400 | | | |
| 206KPP4** | 3 | 1” | 1.0010 | 2.4409 | 0.6299 | 1.0600 | 4370 | 2320 | 0.47 |
| | | | 25.425 | 62.000 | 16.000 | 26.924 | | | |
| G206KPPB4* | 4 | 1” | 1.0010 | 2.4409 | 0.7087 | 0.9450 | 4370 | 2320 | 0.47 |
| | | | 25.425 | 62.000 | 18.000 | 24.000 | | | |
| 206KRR6 | 1 | 1” | 1.0010 | 2.4409 | 0.6300 | 0.9450 | 4370 | 2320 | 0.75 |
| | | | 25.425 | 62.000 | 16.000 | 24.000 | | | |
| 206KRRB6 | 2 | 1” | 1.0010 | 2.4409 | 0.6300 | 0.9450 | 4370 | 2320 | 0.75 |
| | | | 25.425 | 62.000 | 16.000 | 24.000 | | | |
| G207KPPB2* | 4 | 1 1/8” | 1.1260 | 2.8346 | 0.7480 | 1.4840 | 5770 | 3150 | 1.10 |
| | | | 28.600 | 72.000 | 19.000 | 37.694 | | | |
| 207KRRB9 | 2 | 1 1/8” | 1.1260 | 2.8346 | 0.6690 | 1.4840 | 5770 | 3150 | 1.10 |
| | | | 28.600 | 72.000 | 17.000 | 37.694 | | | |
| 207KRRB12 | 2 | 1 1/8” | 1.1260 | 2.8346 | 0.6690 | 0.9840 | 5770 | 3150 | 0.87 |
| | | | 28.600 | 72.000 | 17.000 | 25.000 | | | |
| GW208PPB22* | 4 | 1 1/4” | 1.2510 | 3.1496 | 0.8270 | 1.4380 | 7340 | 3650 | 1.50 |
| | | | 31.877 | 80.000 | 21.000 | 36.520 | | | |
| W208KRRB6 | 2 | 1 3/8” | 1.3760 | 3.1496 | 0.8270 | 1.4380 | 7340 | 3650 | 1.31 |
| | | | 34.950 | 80.000 | 21.000 | 36.520 | | | |
| W208PPB16 | 4 | 1 1/4” | 1.2510 | 3.1496 | 0.7090 | 1.4380 | 7340 | 3650 | 1.45 |
| | | | 31.775 | 80.000 | 18.000 | 36.520 | | | |
| W208PP21 | 3 | 1 1/4” | 1.2510 | 3.1496 | 0.7090 | 1.4380 | 7340 | 3650 | 1.45 |
| | | | 31.775 | 80.000 | 18.000 | 36.520 | | | |
| G209KPPB2* | 4 | 1 1/2” | 1.5010 | 3.3465 | 0.7480 | 1.1810 | 7350 | 4150 | 1.26 |
| | | | 38.125 | 85.000 | 19.000 | 30.000 | | | |
| G5209KYYB2* | | 1 1/2” | 1.5010 | 3.3465 | 1.1811 | 1.2992 | 9330 | 7580 | 1.27 |
| | | | 38.125 | 85.000 | 30.000 | 33.000 | | | |
| 209KRRB2 | 2 | 1 1/2” | 1.5010 | 3.3465 | 0.7480 | 1.1810 | 7350 | 4150 | 1.27 |
| | | | 38.125 | 85.000 | 19.000 | 30.000 | | | |
| 210PPB20 | 3 | 1 1/4” | 1.2550 | 3.5433 | 0.8661 | 1.4350 | 9070 | 5675 | 2.00 |
| | | | 31.877 | 90.000 | 22.000 | 36.450 | | | |
| 210PP20 | 3 | 1 1/4” | 1.2550 | 3.5433 | 0.8661 | 1.4350 | 9070 | 5675 | 2.05 |
| | | | 31.877 | 90.000 | 22.000 | 36.450 | | | |
| G210KPPB2* | 4 | 1 1/4” | 1.5010 | 3.5433 | 0.8661 | 1.1811 | 7780 | 4650 | |
| | | | 38.125 | 90.000 | 22.000 | 30.000 | | | |
| GC211-32-NLC* | 3 | 1 3/4” | 1.7510 | 3.9370 | 0.9840 | 2.2500 | 9740 | 5850 | 3.35 |
| | | | 44.475 | 100.000 | 25.000 | 57.150 | | | |
206KRR6 Agricultural Machinery Bearing Competition Advantages:
1. Coaxiality of the sealing contact surface means that the sealing function and service life have been significantly improved
2. The outer cover extends toward the width of the sealing ring to ensure the protection of the sealing lip against mechanical damage.
3. Galvanized inner cover and outer cover
206KRR6 Agricultural Machinery Bearing Applications:
1. Plough disc connection bearing
2. Tillers, tractors, lawn harvesters
3. Balers and high-power harvesting machines
4. Such as green feed harvesters and combine harvesters
206KRR6 Agricultural Machinery Bearing Features:
1. High quality through hardened bearing steel used for basic construction.
2. Optimized raceway geometry and super finishing.
3. High precision accuracy and manufacturing consistency.
4. Proprietary high performance sealing options.
5. Premium grease as lubrication system.
Shipping Method:
1. For small amount (GW<100KGS), we can send you by express, such as DHL, Fedex, TNT etc
2. For GW between 100KGS to 500KGS, we can send you by sea shipping or air shipping
3. For large amount (GW > 500KGS), we can send you by sea
Factory Photo:
How to place an order:
1. Send us your bearing inquiry, including your bearing models, your quantity. If you have brand requirement, please tell us which brand do you need as well.
2. We will quote bearing price for you. Moreover, According to the quantity of goods, we will give you different options of transportation.
3. If you agree with our price, we will make proforma invoice for payment.
4. After payment is done, we will start to prepare bearings and arrange shipment.
FAQ:
Q1: Are you trading company or manufacturer ?
A: We are factory and professional manufactuer of bearings.
Q2: Can I get a sample to check out the quality ?
A: Sure, free samples are available for stock products if you can payfor the shipping cost.
Q3: Can you do OEM to print my logo/brand on the products ?
A: Yes, we can print your logo/brand on the products, you just need to send us your logo/brand files, we will show you how it looks like before shipping out.
Q4: How long is your delivery time ?
A: Generally we have regular stocks for standard bearings that can be shippedin 2 days after your payment. It will take 15-35 days for new production order, which depends on your order quantity.
